Study site and context

Cambodia is part of the Indo-Burma biodiversity hotspot (Mittermeier et al. 1999). Its forests are home to hundreds of rare and endemic species of plants and animals (Hayes et al. 2015). Cambodia also has one of the highest rates of deforestation in the world (Milne 2015), despite having Asia’s most extensive protected area management systems on paper, with 32 protected areas covering more than 45,000 km² (Theilade and de Kok 2015). After the suspension of the national logging concession system in 2001, which mostly operated outside protected areas (Anon 2004), the Cambodian government started granting economic land concessions inside protected areas. As of 2012, a total of 113 such concessions had been granted inside Cambodia’s protected forests (ADHOC 2012; HRC 2012). Recent remote sensing of the forests by U.S. MODIS/FIRMS suggests that deforestation rates are as high inside Cambodia’s protected areas as they are outside (Peter and Pheap 2015).

The focus of this study was a forest area named Prey Lang (see Figure 1) along with a monitoring program implemented by a network of local forest activists, the Prey Lang Community Network (PLCN), and scientists from the University of Copenhagen (UCPH). Prey Lang is the largest lowland evergreen forest complex in the Indo-Burma biodiversity hotspot (Hayes et al. 2015). The forest covers about 520,000 ha and supports more than 200,000 people, including Kuy indigenous communities as well as Khmers. The forest forms an integral part of the local culture, and most people in the area directly or indirectly derive their livelihood from it by collecting resin, building materials, medicine, and food from the forest (Jiao et al. 2015; Hayes et al. 2015). The PLCN was formed by local village groups in the 2000s to document illegal logging activities associated with economic land concessions granted in the forest in the years 2002 to 2007 but frequently operating outside their designated areas. Since 2009, the PLCN has been working voluntarily and independently through externally funded projects to protect Prey Lang, by undertaking its own forest patrols to intercept illegal loggers and to seize chainsaws and other logging equipment. The PLCN has advocated for Prey Lang’s protection since 2004. It has called for the government to acknowledge PLCN and the local communities in Prey Lang as partners in the future management of the forest. The primary objective of the monitoring program featured in this study has been to support this advocacy effort by documenting the logging as well as the important biodiversity in Prey Lang.

In 2016, following pressure from PLCN and other grassroots organizations as well as a wide range of national and international institutions, Prey Lang was included in the national protected area network. Despite this, the Prey Lang area has, as of February 2017, remained the focus of large-scale conversion to agriculture and plantations (see Figure 1), and the forest itself has been the continued target of logging of high value timber species. Several violent conflicts have occurred as villagers are forcefully removed from their ancestral lands, sometimes by the military (Global Witness 2009). As of February 2017 (the end of this study), no reduction in illegal logging was found based on monitoring data. The PLCN has indicated that it will continue its patrols until actual protection is implemented by the government.

Design and development of the app

We held a five-day initiation workshop in August 2014 with 34 participants, selected by the PLCN and coming from all four Cambodian provinces in which the PLCN operates. We employed participatory mapping to identify forest areas used by communities and defined the overall aim of the monitoring program in a series of focus group discussions. In these discussions, we used free-listing to identify resources and activities to be monitored. Afterwards we grouped resources and activities into categories to guide the design of monitoring methods. We decided that the PLCN would have ownership of all produced monitoring data, and that no data could be shared without its permission. We selected a smartphone application based on the Sapelli Platform (see Stevens et al. 2014), developed specifically for use by local people with limited experience of technology, as the primary monitoring tool. The app was developed by a local IT company, based on the PLCN’s input during the workshop and its feedback on a first prototype decision tree presented on the last day of the workshop.

The application, designated the “Prey Lang App” (henceforth the PLA), compiled three types of information: (i) Reference data. As soon as a new data point was created, metadata including time and date, GPS coordinates, and phone id was automatically attached to the observation. (ii) Primary documentation. Upon establishment of a new data point, the patroller documented the observation with a photo and an optional audio recording, using the smartphone’s built in camera and recorder. (iii) Thematic tag. The patroller tagged the observation using a decision tree with three main categories: Illegal activities, Resources, and Reporting to authorities. Each main category had a number of pre-set sub-categories (see Appendix 1A, supplemental materials).

After registration of observations in the field, the data points were automatically uploaded to an online database via the cell phone network. Next, the data were validated by a database manager based on pre-established validation criteria (see Appendix 2, supplemental materials).

The first version of the PLA (Version 1) was designed to primarily collect quantitative information on a limited number of resources and interactions to minimize complexity and encourage systematic use during patrolling. Categories in the decision tree were all illustrated by pictures to allow participants with low literacy to navigate the PLA more easily. It was tested by a group of 40 PLCN members, using 20 Samsung Galaxy devices, at a seven-day field trial in December 2014. The field trial featured an initial three-day training course aimed at familiarizing the participants with the functionality of the PLA and smartphones in general, followed by a three-day field trial with various monitoring exercises. It concluded with a one-day evaluation of the PLA functionality and the monitoring experience. The consensus in the evaluation was that the version was too limited in scope, and a strong wish to be able to give qualitative descriptions of interactions was expressed. This input was used to inform the design of an updated version of the PLA (see Appendix 1B, supplemental materials), developed in January 2015. Data collection using this version (Version 2), running on 36 Samsung Galaxy devices, commenced in February 2015. This work was initiated in a seven-day field training course in Prey Lang, featuring a two-day refresher training focusing on familiarizing participants with the new functionality added to the PLA, followed by five days of supervised patrolling and monitoring in Prey Lang. This marked the beginning of actual data collection with the PLA.

Version 2 of the PLA was in service for 11 months, during which the PLCN continually provided feedback on functionality and operational challenges. This feedback was used to develop Version 3 of the PLA, which became operational in December 2015. This version featured a significantly extended decision tree as well as a number of bug fixes (see Appendix 1B, supplemental materials). Version 3 operated for seven months until the release of Version 4 in August 2016. The guiding principle for all PLA updates was to fit the design of the application closer to the needs of the PLCN, and at the release of every new version, one- to two- day refresher trainings were conducted in the individual provinces to familiarize the PLCN patrollers with the added functionality.

In January 2017, 24 PLA users attended a two-day evaluation of the app and provided input for development of Version 5 (released in August 2017). The evaluation was conducted using individual questionnaires featuring open-ended questions on experiences that users had in working with the PLA and participating in the monitoring program. This was followed by a mediated plenum discussion of the questionnaire results and formulation of recommendations for the Version 5 design.

The monitoring program

In total, 36 patrollers were involved in monitoring using the PLA. They all were selected by the PLCN based on volunteerism and experience with either patrolling or using smartphones. In total, 30 male and 6 female PLCN members were involved, ranging from 18 to 61 years of age (see Appendix 3, supplemental materials).

The PLCN did the data collection with the PLA as part of existing patrolling activities. Since 2009, these have included regular and ad-hoc local forest patrols multiple times each month and large scale patrols, covering the Prey Lang core area, a couple of times per year (see Appendix 4, supplemental materials). Local patrols were organized by local PLCN members at regular intervals or in response to rumors of illegal activities in the local forest area. They were generally composed of 8 to 10 people on motorbikes or on foot (depending on the planned range of the patrol and the condition of the roads), and rarely targeted forest areas farther than 15 km from the villages where the involved PLCN members lived. The primary objective of these patrols was to discourage local level illegal logging by confiscating logging equipment and turning it over to the authorities, along with reports of recorded incidents. By using the PLA to record interactions with loggers, along with evidence of logging activity and important resources or biodiversity found, these local patrols were a central part of the PLA program. Large patrols were organized by a PLCN steering committee in collaboration with local PLCN core members, and generally targeted the Prey Lang core area, as this is far from most villages and thus rarely visited on local patrols. Large patrols served similar purposes as local patrols of discouraging logging and documenting illegal activities, but would also be announced in local and national media to raise awareness of the illegal logging in Prey Lang. The PLA was extensively applied during these patrols as well, as many PLA users participated. Data recorded with the PLA during both local and large patrols was compiled in quarterly monitoring reports by a team of data managers from the University of Copenhagen. The data were published in both English and Khmer and presented to the general public by PLCN members at press conferences held in Phnom Penh. These press conferences were an important part of the PLCN’s overall advocating strategy for the protection of Prey Lang.

Since 2009, PLCN members have received training in peace building and non-violence methods (as described by Galtung 1985). During all patrols, the PLCN used these methods when interacting with people found engaging in illegal activities. Despite the logging in Prey Lang being associated with a high level of conflict, no PLCN patroller carried any weapons, and the only security measures applied were patrolling in large groups and actively seeking to de-escalate heated encounters through dialogue.

Do local communities have the capacity to collect valid information using ICT?

We found that the community members of Prey Lang Community Network had made 10,842 entries of data on observed forest resources and signs of illegal logging in the database over the 24 month period. A total of 4,560 entries (42.1%) were successfully validated by the external data managers, whereas 1,303 entries (12.0%) were excluded because of human error and 4,979 entries (45.9%) were excluded because of technical error. The distribution of entries over time within the main categories provided in the decision trees is shown in Table 1, and examples of entries within the three main categories are found in Figure 2.

The rate of data production fluctuated between months, with more than five times as many entries in the most productive month (14^th month) as in the least productive (8^th and 18^th months; see Figure 3). On 588 days out of the 730 days in the two-year period (80.5% of days), at least one entry was recorded, with several spikes in data entry generation coinciding with large-scale patrolling activities. The relative number of entries excluded because of human error was considerably lower than the number of entries excluded because of technical error.

When asked their opinion on the monitoring program, 20 of the 24 patrollers who answered the questionnaire stated that they understood the PLA and felt that they were able to use it correctly (20 January 2017). Challenges associated with learning how to use new functionality added in Versions 3 and 4 came up during the plenum discussion of the questionnaire results. Eleven patrollers mentioned that it took them a few tries to navigate the updated decision tree end points and use the drop-down menus added in Version 3, which they concluded probably led them to upload some erroneous entries in the first months following the release of Version 3.

When asked to free-list challenges encountered and priorities for future PLA development, 16 patrollers specifically mentioned problems with uploading data as a key concern. They all mentioned the scarcity of areas with stable mobile phone connection in the provinces as a major cause of this, with one stating: “It is not possible to get a signal in my village and I have to travel to Thala Barivat [Stung Treng Province] to get a signal strong enough to upload my data. Therefore my phone memory is often full.” (PLCN patroller)

Does the complexity of the ICT tool affect the ability of community patrollers to use it?

We found that, although the complexity increased with each new PLA version, the proportion of submitted entries successfully validated increased over time (Table 2). The number of entries excluded because of technical errors decreased slightly with the implementation of Version 3 (which included changes specifically designed to address data uploading issues experienced with Version 2), but remained high at around 40% in Versions 3 and 4. A summary of specific inputs and implemented changes to the PLA can be found in Appendix 1B, supplemental materials.

In the evaluation, 8 out of the 24 patrollers wished to have access to more functions, including the ability to take videos (in addition to photos and audio recordings), addition of maps to see areas of previous patrolling activity and satellite imagery of the forest, and addition of more species to the drop-down menus. In contrast, 2 patrollers thought the PLA (Version 4) had become too complex, both mentioning the introduction of drop-down menus to add specific species for trees, NTFPs, and animals in Version 3 as the function that is most difficult to use.

Do age and gender affect the successful use of ICT in monitoring programs?

We found no significant differences (p > 0.05 – mixed logit model) in the proportion of validated entries produced between gender and age groups. A few patrollers in the age group 36–51 years had particularly high validation percentages, but the age group as a whole did not perform significantly better than the 19–24 year reference age group (p = 0.07). Older people tended to submit more entries than younger people, and men generally submitted more entries than women (Table 3).

How much does it cost to develop and implement an ICT-based monitoring system?

We found that, from the inception workshop in August 2014 to the end of the first two years of monitoring in February 2017, the cost of developing and operating the monitoring program was $136,634 US (Table 4). This is equal to $0.26 US/ha/year and $29.96 US per validated entry. Approximately one third of the total cost was spent by the PLCN and local partners ($51,110 US), one third by UCPH ($45,253 US), and one third by the IT company that developed the software ($39,915 US). While PLA development was ongoing throughout all three phases, 45% of the total cost of the monitoring program was spent on PLA development (this figure does not include costs for training and consultation needed with the release of every new version of the PLA). The remaining costs were spent operating the monitoring program. Development costs increased by 16% from the first to the second year, while operation costs decreased by 15% (see details in Appendix 5, supplemental materials).

Many of the costs of operating the monitoring program were borne by the PLCN members who volunteered their time on patrols, at meetings, and for coordination of activities. These costs are not included in the cost calculations.

Validity of the data recorded

Our results show that over a two-year period, the PLCN was able to produce 4,560 successfully validated data entries on forest resources and illegal logging in Prey Lang, constituting 42.1% of all entries submitted. The capacity of the PLCN to use the PLA correctly had a minor impact on the data with only 12.0% of entries being excluded because of human error as compared to the 45.9% discarded because of technical errors. The technical errors experienced were predominantly caused by the limited availability of mobile network coverage in the remote areas of Prey Lang, making it difficult to upload entries with multiple pictures. Other errors were related to bugs in the PLA that occurred during development (e.g., failure to include GPS coordinates of certain types of observations; scrambling of pictures when more than five pictures were added to a data point). While these software errors were mostly corrected with the releases of Versions 3 and 4, they still accounted for upwards of 10% of all technical errors recorded.

In all months, the number of entries excluded because of human error was considerably lower than the number of entries excluded because of technical errors (except months 1–3 and 12–14). The errors in months 1–3 might be attributed to the patrollers’ inexperience with the PLA. The release of Version 3 in month 11 (December 2015), which saw a large amount of functionality added to the PLA has, as mentioned by 11 patrollers in the evaluation, had a temporary effect on their ability to use the app correctly, and probably led to human errors in months 12–14. These observations, combined with the general decrease in prevalence of human error in entries over the two-year period, suggest that the patrollers went through a positive learning curve over time, similar to effects found in REDD+ community Monitoring Reporting and Verification (Brofeldt et al 2014). Moreover, we found no evidence that using ICT predisposes any particular demographic group to be better patrollers other than the finding that the age group 36–51 had some of the most capable patrollers of all. We also found no negative effect of app complexity on the ability of patrollers to use the PLA correctly. In contrast, the proportion of entries successfully validated increased with app complexity (Table 2). This is presumably because app development was slower than the learning rate achieved by PLCN members. Our findings suggest that the applied ICT technology’s inherent main challenge, signal constraints when operating in a remote area with limited phone service, is a more significant constraint than the ability of community members to use the technology correctly. Similar limitations imposed by phone connectivity have been documented in application of ICT in rural farming systems in Ghana and Tanzania (Kalusopa 2005; Dhaka and Chayal 2010; Shah et al. 2014). Here it was found that limitation in phone connectivity was as severe a constraint to implementation as linguistic barriers (Shah et al. 2014) and lack of interest in using the tool among community members (Kalusopa 2005; Dhaka and Chayal 2010).

Extent of community involvement

The incorporation of the PLCN’s input and priorities into the ongoing app development process has allowed for a continuous high level of community engagement in the monitoring. A large number of PLCN members were profoundly involved at several stages of the development, including both the conceptualization, design, implementation, and analysis steps. This level of community involvement is uncommon among CBM programs making use of ICT (Brammer et al. 2016). The collaboration between the PLCN and researchers from UCPH can be defined as collaborative monitoring with local data interpretation (sensuDanielsen et al. 2009 – “Type B” by Danielsen et al. 2013b and Brammer et al. 2016), with the addition that data interpretation was done collaboratively, as opposed to by the community independently. This was achieved by database managers from UCPH initially analyzing uploaded entries quantitatively and then presenting the results to the PLCN, who undertook interpretation of the presented data and the establishment of causal relationships; see Figure 4.

The work of the PLCN over the two-year period covered by this study also supports the findings by Brammer et al. (2016) that the participatory nature of the program and the use of digital devices assured reporting of management actions such as confiscation of logging equipment and illegally felled timber. Moreover, Brammer et al. (2016) found that CBM programs were more frequently reported as ongoing than programs not involving volunteers, but that employing digital data entry into the CBM program had a negative effect on the sustainability of monitoring programs. Our study supports the first finding, as PLCN had patrolled on a voluntary basis for more than a decade before the PLA was developed, but the introduction of ICT does not appear to have discouraged overall community participation. We believe that the sustainability is expedited by alignment of stakeholder objectives and the ease of using the PLA. Hence, our study supports the notion that innovative technologies attract interest, but the foundation of effective CBM depends more on collaboratively defined questions, objectives, conceptual models, and monitoring approaches. When this foundation is built through effective partnerships, digital data entry can enable the collection of more data of higher quality (Brammer et al 2016).

The increased complexity of the PLA with every new version of the software was based on PLCN specifically requesting additional functionalities. The learning that the patrollers have gained from their involvement in this process, and the associated ownership and commitment generated, are likely to have had a positive effect on the PLCN patrollers’ ability and motivation to further develop their skills and apply the new functionality. This is in line with comments made by PLA users during the evaluation, that they felt their inclusion in app design had given them an increased understanding of how to use the app correctly. Ens (2012) found a similar benefit of involving local community monitors in the design of monitoring tools for rangelands in Australia.

While the PLA was an entirely new tool for the PLCN patrollers, it was incorporated into an existing patrolling paradigm that the patrollers were well familiar with. Some spikes in data generation (Figure 2) are likely caused by fluctuations in logging or small scale patrolling activity, while a number of periods of high entry generation appear to coincide with large patrols (see Appendix 4, supplemental materials). While both small and large scale monitoring activities generated many entries, 1,456 of entries (13.5%) were generated on days with ten or fewer entries. These few entries are unlikely to have been generated during patrols, because even small scale local patrols generally feature a minimum of 15–20 entries recorded (assessment by PLCN patrol leader in private conversation during evaluation workshop in January 2017). Therefore, the entries are likely recorded by the PLCN patrollers using the PLA during their daily activities in the forest. In a ranger based monitoring program, where rangers do not necessarily live in the area or pursue monitoring activities while off duty, collecting data in this way would have been impossible. This suggests that the high level of community involvement brought with it an intrinsic benefit of CBM of forests–namely the constant presence of the PLCN in the area.

Cost of the PLA monitoring program

The PLA monitoring program cost of $0.26 US/ha/year is notably lower than costs found for similar monitoring programs implemented by professional rangers ($4.60 US/ha/year found by A. McNeilage; cited in Danielsen et al. 2005) but slightly above the median cost of $0.10 US/ha/year found by Danielsen et al. (2005; inflation-adjusted figures) in a review of thirteen CBM projects. Those projects took place at different locations and times than the PLA, which limits their applicability for direct comparison to the cost found using the PLA. They also all featured simpler monitoring methods, no (or very limited) use of ICT, and longer intervals between successive bouts of data collection, which might partly explain the higher cost of the PLA program. Nonetheless, this suggests that ICT-based CBM can be cost effective when compared to professional forest monitoring, but the development costs of the ICT tools generally makes ICT-based CBM more expensive than CBM done without the use of ICT. While the overall cost of the program did not change notably from the first to the second year, the operation costs dropped by 15%, counterbalanced by a 16% increase in PLA development costs. The decreasing operating costs are consistent with previous findings, indicating that increases over time in capacity, organization, and engagement of involved monitors lead to more cost-effective CBM (Brofeldt et al. 2014). This effect might have been more pronounced had the monitoring program been implemented outside the PLCN’s existing patrolling activities, within a freshly formed community group. In many CBM programs (including the ones described by Brofeldt et al. 2014), community engagement and organization had to be developed from scratch, potentially incurring a greater initial operating cost than in the present study. The development costs in both years predominantly went to the involvement of UCPH and the web developers, for developing the four versions of the PLA, maintaining the app, and managing the data. While developing new PLA versions might not continue to be relevant, app maintenance and support for data management will remain necessary for as long as the CBM program is running. This significantly increases the reliance of the PLCN on outside support. The importance of independence from this type of outside support for the sustainability of a CBM program is well documented (Danielsen et al. 2005; Becker et al. 2005; Ens 2012; Brammer et al. 2016), and in the case of the PLCN’s work in Prey Lang, is a tradeoff for the increased data quality achieved.

Implications for the future management of Prey Lang

Given the average human population density in the four Prey Lang provinces (24.8 people/km²)² and the continued occurrence of logging activities, managing the forest as a protected area will require monitoring of the illegal activities and enforcement of the forest protection. The increasing proportion of successfully validated reports on forest resources and illegal logging generated by the PLCN using the PLA is promising. During the inception workshop in August 2014, project partners discussed whether to incorporate the registration of count per unit effort (CpUE) into the monitoring program to allow for quantification of results despite various levels of monitoring intensity. This idea was rejected by the PLCN, as it did not feel that it would be necessary for its monitoring objectives. Members also thought that it would be hard to adopt into existing patrolling routines. If Prey Lang management required quantifiable information of resources or activities, adopting a CpUE into the PLA program would however be possible, although other studies have questioned the necessity of effort-corrected information on forest protection (Gray and Kalpers 2005).

The PLCN has repeatedly communicated to the Cambodian government its willingness to undertake monitoring of Prey Lang in exchange for involvement in forest management decision making and recognition of its forest rights (Argyriou et al. 2015a; 2015b; Argyriou et al. 2017). Several studies have documented the benefits to forest protection of community involvement in monitoring and management (Chazdon 2008; Agrawal and Angelsen 2009; Somanathan et al. 2009; Danielsen et al. 2011). However, successful protection of the forest will require establishing government-recognized local land rights, because distrust between communities and the local authorities may otherwise continue to undermine any benefits for both communities and forest protection (Mahanty et al. 2013; Pham et al. 2014).

Without PLCN’s CBM program, monitoring of illegal logging and forest resources in Prey Lang would not be occurring. However, the PLCN will be unlikely to continue the ICT-based monitoring efforts without financial support for database management, purchasing of equipment, maintenance of the app, and analyses and reporting of the results. The low monitoring cost achieved by the PLCN despite its dependence on outside support for PLA development and operation could be an argument for their future involvement in management of Prey Lang as a protected area. Whatever the future funding available for management of Prey Lang as a protected area, a cost-effective monitoring system will be important for managing pressure on the forest from destructive activities.
